10A 300V 14PIN Relay socket CD14A-E Manufacturer of the Industrial Control Products CDGKZ
| Product model | CD14A-E |
| Rated current | 10A |
| Rated voltage | 300V |
| Dielectric strength | 2500V/S |
| Screw torque | 1.0Nm |
| External connection wire | 20-14/0.5-2.5AWG/mm² |
| Ambient temperature | -40℃-+85℃ |
| Weight | 42G |
| Adapter relay | Siemens, Schneider, TE, Eaton, Weidmuller |
Product Details
Outline dimensions/Mount dimensions(mm)
Performance Parameters
Key Technical Features:
The CD14A-E relay socket delivers stable electrical performance, robust mechanical reliability, and long-lasting durability for demanding industrial applications.
Electrical Ratings
- Rated current of 10A, supporting reliable medium-load switching applications.
- Rated voltage up to 300V, ensuring safe performance in industrial control environments.
- Dielectric strength 2500V/S, providing strong insulation and electrical safety.
Mechanical & Installation Features
- Screw torque rated at 1.0Nm for secure terminal fastening.
- Compatible with external connection wires 20–14 AWG / 0.5–2.5mm², supporting flexible wiring options.
- Standardized socket design ensures quick installation and reliable relay mounting.
Environmental Conditions
- Wide ambient temperature range from –40℃ to +85℃, suitable for harsh industrial environments.
- Resistant to thermal stress and operational fluctuations, ensuring long-term durability.
- Stable performance under vibration and varying humidity conditions.
Physical Characteristics
- Compact design with a weight of 42g, optimized for panel space efficiency.
- Built with robust housing material for mechanical stability and electrical insulation.
- Precision-engineered contacts for secure relay seating and long service life.
The product perfectly fits Siemens, Schneider, TE, Eaton, and Weidmuller relays, while offering superior socket quality beyond leading international brands.
Structural & Functional Advantages
CD14A-E
Mounting Options
Compatible with both DIN rail and panel mounting, simplifying cabinet integration
Screw Terminal Design
Ensures firm wiring and mechanical reliability, reducing risk of loose contacts
Black Flame-Retardant Base
Enhances durability and visibility in control panels
Hook-Compatible Design
Supports optional hook (e.g., 10F-G) for enhanced locking and anti-fall capability
Broad relay compatibility
Siemens, Schneider, TE, Eaton, Weidmuller
Application Scenario
Industrial Control Systems
PLCs, motor controls, and automation equipment
Electrical Panels
Distribution boards and power supply units
Home Appliances
Wiring for household devices and equipment
FAQ
1.What is the rated electrical performance of the CD14A-E relay socket?
The socket supports a rated current of 10A and a rated voltage of 300V, with a dielectric strength of 2500V/S, ensuring high electrical insulation and safety in demanding industrial environments.
2.What type of external wiring does this socket support?
It accommodates 20–14 AWG (0.5–2.5 mm²) external connection wires, providing flexible compatibility with standard industrial cabling sizes.
3. What are the mechanical installation specifications?
The socket requires a screw torque of 1.0 Nm for secure fastening, ensuring stable mechanical reliability during vibration and long-term operation.
4.What environmental conditions can the CD14A-E operate in?
It is designed for a wide ambient temperature range of -40℃ to +85℃, making it suitable for harsh industrial and outdoor applications.
5. What is the physical profile of the socket?
The socket weighs 42 grams, providing a compact yet robust construction for efficient panel space utilization.
6.Can this product be used with Siemens, Schneider, TE, Weidmuller and Eaton relays?
Yes. It is perfectly compatible with Siemens, Schneider, TE, Eaton, and Weidmuller relays, and its socket quality surpasses international brands.
