7A 300V 14PIN Relay socket CD14AN-E Manufacturer of the Industrial Control Products CDGKZ
| Product model | 18F-4Z-C1 |
| Rated current | 7A |
| Rated voltage | 300V |
| Dielectric strength | 2000V/S |
| Screw torque | 1.0Nm |
| External connection wire | 20-14/0.5-2.5AWG/mm² |
| Ambient temperature | -40℃-+65℃ |
| Weight | 49G |
| Adapter relay | Siemens, Schneider, TE, Eaton, Weidmuller |
Product Details
Outline dimensions/Mount dimensions(mm)
Performance Parameters
Key Technical Features:
The 18F-4Z-C1 delivers secure connections, high insulation reliability, and wide compatibility for industrial control systems under demanding environments.
Electrical Ratings
Rated current: 7A ensures reliable load handling for industrial applications.
Rated voltage: 300V supports broad control system integration.
Dielectric strength: 2000V/S guarantees excellent insulation and safety margin.
Mechanical & Installation Features
Screw torque: 1.0Nm provides secure terminal tightening, preventing loosening under vibration.
External connection wire range: 20–14 AWG / 0.5–2.5 mm² allows flexible wiring options for different setups.
Environmental Conditions
Ambient temperature: -40℃ to +65℃, suitable for harsh industrial and outdoor environments.
Physical Characteristics
Compact weight: 49g, ensuring easy DIN-rail or panel installation without additional load.
Adapter relay compatibility: Siemens, Schneider, TE, Eaton, Weidmuller, enabling universal interchangeability.
The product perfectly fits Siemens, Schneider, TE, Eaton, and Weidmuller relays, while offering superior socket quality beyond leading international brands.
Structural & Functional Advantages
18F-4Z-C1
Mounting Options
Compatible with both DIN rail and panel mounting, simplifying cabinet integration
Screw Terminal Design
Ensures firm wiring and mechanical reliability, reducing risk of loose contacts
Black Flame-Retardant Base
Enhances durability and visibility in control panels
Hook-Compatible Design
Supports optional hook (e.g., 10F-G) for enhanced locking and anti-fall capability
Broad relay compatibility
Siemens, Schneider, TE, Eaton, Weidmuller
Application Scenario
Industrial Control Systems
PLCs, motor controls, and automation equipment
Electrical Panels
Distribution boards and power supply units
Home Appliances
Wiring for household devices and equipment
FAQ
1.What is the rated electrical performance of the 18F-4Z-C1 relay socket?
The 18F-4Z-C1 supports a rated current of 7A and a rated voltage of 300V. It also provides dielectric strength of 2000V/S, ensuring reliable insulation and safe operation in industrial control applications.
2.What are the recommended wiring and installation parameters?
This relay socket supports external connection wires of 20–14 AWG (0.5–2.5 mm²). The screw torque requirement is 1.0 Nm, which guarantees secure and vibration-resistant terminal fastening.
3. How does the socket perform under different environmental conditions?
The 18F-4Z-C1 is designed to withstand ambient temperatures from –40℃ to +65℃, making it suitable for harsh industrial environments, including cold storage, outdoor panels, and high-temperature machinery.
4.What are the mechanical and physical characteristics of this model?
The socket weighs 49g, providing a compact yet robust housing that supports stable relay seating. Its design enables quick installation on DIN rails or control panels without compromising structural integrity.
5. What safety and reliability benefits does the socket offer?
With strong dielectric performance, vibration-resistant screw connections, and a wide operating temperature range, the 18F-4Z-C1 enhances long-term system safety, reduces downtime, and improves electrical reliability in demanding applications.
6.Can this product be used with Siemens, Schneider, TE, Weidmuller and Eaton relays?
Yes, it is fully compatible with Siemens, Schneider, TE, Eaton, and Weidmuller relays. Moreover, its socket quality surpasses international brands, offering superior durability and electrical performance.
