10A 300V 8PIN Relay socket 14F-2Z-C2 Manufacturer of the Industrial Control Products CDGKZ
| Product model | 14F-2Z-C2 |
| Rated current | 10A |
| Rated voltage | 300V |
| Dielectric strength | 4000V/S |
| Screw torque | 1.0Nm |
| External connection wire | 20-14/0.5-2.5AWG/mm² |
| Ambient temperature | -40℃-+65℃ |
| Weight | 37G |
| Adapter relay | Siemens, Schneider, TE, Eaton, Weidmuller |
Product Details
Outline dimensions/Mount dimensions(mm)
Performance Parameters
Key Technical Features:
The 14F-2Z-C2 relay socket offers high dielectric strength, secure connections, and reliable performance in industrial automation environments.
Electrical Ratings
- Rated current of 10A ensures reliable load handling for industrial relay applications.
- Rated voltage of 300V provides safe operation in control and automation circuits.
- High dielectric strength of 4000V/S guarantees strong insulation and electrical safety.
Mechanical & Installation Features
- Screw torque of 1.0Nm enables secure and vibration-resistant wire connections.
- Compatible with external connection wires from 20–14 AWG / 0.5–2.5mm² for flexible installation.
- Robust screw terminals ensure stable mechanical mounting in demanding environments.
Environmental Conditions
- Wide ambient temperature range from -40℃ to +65℃ allows operation in harsh industrial conditions.
- Designed to maintain reliable performance under varying environmental stresses.
Physical Characteristics
- Compact weight of 37g supports easy integration into control panels without excess load.
- Optimized housing design provides durability and long-term reliability in continuous operation.
The product perfectly fits Siemens, Schneider, TE, Eaton, and Weidmuller relays, while offering superior socket quality beyond leading international brands.
Structural & Functional Advantages
14F-2Z-C2
Mounting Options
Compatible with both DIN rail and panel mounting, simplifying cabinet integration
Screw Terminal Design
Ensures firm wiring and mechanical reliability, reducing risk of loose contacts
Black Flame-Retardant Base
Enhances durability and visibility in control panels
Hook-Compatible Design
Supports optional hook (e.g., 10F-G) for enhanced locking and anti-fall capability
Broad relay compatibility
Siemens, Schneider, TE, Eaton, Weidmuller
Application Scenario
Industrial Control Systems
PLCs, motor controls, and automation equipment
Electrical Panels
Distribution boards and power supply units
Home Appliances
Wiring for household devices and equipment
FAQ
1.What are the electrical performance ratings of the 14F-2Z-C2 relay socket?
The socket supports a rated current of 10A and rated voltage of 300V, with a dielectric strength of 4000V/S, ensuring reliable insulation and electrical endurance in demanding industrial applications.
2.How is the mechanical connection designed for secure installation?
The socket provides screw terminal connections with a tightening torque of 1.0 Nm, supporting wire sizes from 20–14 AWG (0.5–2.5 mm²), ensuring both safety and long-term stability under vibration or mechanical stress.
3.What environmental conditions can the 14F-2Z-C2 withstand?
It operates within a wide ambient temperature range of -40℃ to +65℃, allowing stable performance in harsh climates and demanding industrial control cabinets.
4.What are the key physical characteristics of this relay socket?
The socket weighs only 37 g, making it lightweight yet robust, suitable for dense panel layouts without compromising mechanical durability.
5. What certifications or compliance standards are typically associated with this socket?
While certification may vary by order, the socket design aligns with UL and IEC safety requirements, making it suitable for global industrial automation markets.
6.Can this product be used with Siemens, Schneider, TE, Eaton, and Weidmuller relays?
Yes, it is perfectly compatible with Siemens, Schneider, TE, Eaton, and Weidmuller relays. Moreover, the socket’s quality surpasses many international brands, offering enhanced reliability and value.
