10A 300V 8PIN Relay socket CDO8AN Manufacturer of the Industrial Control Products CDGKZ
| Product model | CD08AN |
| Rated current | 10A |
| Rated voltage | 300V |
| Dielectric strength | 2000V/S |
| Screw torque | 1.0Nm |
| External connection wire | 20-14/0.5-2.5AWG/mm² |
| Ambient temperature | -40℃-+65℃ |
| Weight | 32G |
| Adapter relay | Siemens, Schneider, TE, Eaton, Weidmuller |
Product Details
Outline dimensions/Mount dimensions(mm)
Performance Parameters
Key Technical Features:
The CD08AN relay socket delivers high reliability, robust insulation, and versatile installation, ensuring safe and stable performance in industrial applications.
Electrical Ratings
- Rated current: 10A, ensuring reliable current handling for industrial relay circuits.
- Rated voltage: 300V with dielectric strength of 2000V/S, guaranteeing insulation safety.
- Designed to minimize power loss and provide stable electrical connections.
Mechanical & Installation Features
- Screw torque: 1.0Nm for secure fastening and vibration resistance.
- Supports external connection wire: 20-14 AWG / 0.5–2.5 mm², suitable for flexible wiring options.
- Compact 32g design ensures easy panel or DIN-rail installation.
Environmental Conditions
- Operates effectively within -40℃ to +65℃, covering wide industrial temperature ranges.
- Built for resistance against industrial environmental stresses.
- Ensures consistent performance under varying humidity and field conditions.
Physical Characteristics
- Lightweight at 32g, reducing installation load.
- Durable structure optimized for long service life.
The product perfectly fits Siemens, Schneider, TE, Eaton, and Weidmuller relays, while offering superior socket quality beyond leading international brands.
Structural & Functional Advantages
CD08AN
Mounting Options
Compatible with both DIN rail and panel mounting, simplifying cabinet integration
Screw Terminal Design
Ensures firm wiring and mechanical reliability, reducing risk of loose contacts
Black Flame-Retardant Base
Enhances durability and visibility in control panels
Hook-Compatible Design
Supports optional hook (e.g., 10F-G) for enhanced locking and anti-fall capability
Broad relay compatibility
Siemens, Schneider, TE, Eaton, Weidmuller
Application Scenario
Industrial Control Systems
PLCs, motor controls, and automation equipment
Electrical Panels
Distribution boards and power supply units
Home Appliances
Wiring for household devices and equipment
FAQ
1.What is the rated current and voltage capacity of the CD08AN socket?
The CD08AN is designed for 10A current and 300V rated voltage, making it suitable for medium-duty industrial applications where both safety and stability are required.
2.How reliable is the dielectric strength of this socket?
The socket has a dielectric strength of 2000V/S, ensuring high insulation safety and minimizing the risk of electrical breakdown under operational stress.
3. What are the recommended wiring specifications?
The CD08AN supports 20-14 AWG (0.5–2.5 mm²) external connection wire, providing flexibility for different wiring setups while maintaining secure conductivity.
4.Can the CD08AN withstand harsh industrial environments?
Yes. With an ambient temperature range of -40℃ to +65℃, the socket operates reliably in both low-temperature and moderately high-temperature conditions, ensuring durability in demanding environments.
5. What installation torque should be applied to the terminal screws?
The recommended screw torque is 1.0 Nm, which ensures optimal tightening force without damaging the terminals, securing long-term stable connections.
6.Can this product be used with Siemens, Schneider, TE, Eaton, and Weidmuller relays?
Yes, the 14F-2Z-C5 relay socket is fully compatible with Siemens, Schneider, TE, Eaton, and Weidmuller relays. Moreover, its contact reliability and housing durability surpass many international brands, ensuring superior long-term performance.
